技术参数
输入电压: AC90-240V 50-60Hz
灯泡: 欧斯朗330W 15R
控制模式: DMX 512, 主从机,声控及自走模式
控制通道:14/16 DMX通道可切换
功率消耗:450W
产品尺寸:430x370x560mm
净重: 23kg
性能特点
高亮度330W 欧斯朗灯泡
7500K 色温，1500小时灯泡寿命
16 bit 高精度水平与垂直旋转
540° 水平旋转角度及270°垂直旋转角度
扫描位置记忆功能,自动纠错复位功能
内置1个旋转图案盘：11个图案+白光
内置1个颜色盘：14个颜色+白光
8 棱镜，方向可自由正反向旋转及雾化功能
灯泡可调半功率功能，可控制灯泡开关
0－100% 线性调光
防反辐射镀膜光学玻璃透镜组
水平垂直快锁便于产品运输及维护
4种操作模式: DMX512, 主从机,声控及自走模式
LCD显示控制面板，正反显示方向可调
3芯和5芯DMX连接头
Specifications
Input Voltage: AC90-240V 50-60Hz
Lamp: Osram 330W Lamp
Control Signal: DMX 512, Master-slave and sound activated or Stand alone
Control Channel: 14/16 DMX Channels
Power Consumption:450W
Dimensions: 430x370x560mm
Net Weight: 23kg
Features
High Brightness Osram 330W Lamp
High precision Optics Glass lens
7500K Color Temperature with 1500 hours lifetime
16 bit smooth and precise resolution for PAN/TILT movement
540° pan and 270° tilt movement
Scan position memory, auto reposition after unexpected movement
Unprecedented brightness-comparable to wattages many times higher
1 Gobo wheel with 11 Gobos Plus Open
1 Color Wheel with 14 colors Plus Open
8-facet rotating prism with variable direction
0-100% Linear dimmer adjustment
Frost Filter, Electronic Focus, High speed shake effect
Rapid and extensive pan and Tilt movements
Lamp power could be controlled by Menu
Power ON/OFF via DMX Controller
Control By 4 Modes: DMX 512, Master/Salve, Sound activity and work auto
Device locking PAN and TILT mechanisms for transportation and maintenance.
LCD Display Control Menu, 180°display could be optional
3-Pin and 5-Pin DMX connectors
